| Model No
|
: |
SSSL-MB-S |
| Light intensity |
: |
Medium intensity Type B (as per ICAO specs), 2000+/- 25% cd
|
| Flashing
|
: |
Flashing 20-60 times per minute (as per ICAO norms)
|
| LED |
: |
Red color with inbuilt Lens for maximum efficiency, no secondary lenses
|
| Led Life |
: |
>50,000 hours |
| No. of LEDs |
: |
560 |
| No of parallel LED circuits
|
: |
56 |
| Shell |
: |
Clear glass (No plastics which deteriorate with time) |
| Bird spike |
: |
Yes |
| ON/OFF control |
: |
Inbuilt LDR |
| Power Consumption |
: |
30W Peakappox |
| Light base |
: |
Made from cast Aluminum with bright orange powder coating |
| Sealent |
: |
Silicon based |
| Environmental protection
|
: |
IP 65
|
| Battery Capacity |
: |
24 AH, 12V
|
| Battery enclosure
|
: |
Separate independently mountable at lower levels, MS Powder coated
|
| Solar Panel |
: |
50 W |
| Charge Controller |
: |
|
| Overcharge Protection |
: |
Yes |
| Deep Discharge protection |
: |
Yes |
| Unit Ventilation |
: |
Natural draft |
| Operating Temp. Range |
: |
0 – 55 deg C |
| Mounting |
: |
Suitable for angular member towers without welding or drilling. Option for Tubular towers also available
|
